Home ProductsZirconia Ceramic Rod

95% high purity high temperature threaded alumina/zirconia ceramic rods

95% high purity high temperature threaded alumina/zirconia ceramic rods

    • 95% high purity high temperature threaded alumina/zirconia ceramic rods
    • 95% high purity high temperature threaded alumina/zirconia ceramic rods
    • 95% high purity high temperature threaded alumina/zirconia ceramic rods
  • 95% high purity high temperature threaded alumina/zirconia ceramic rods

    Product Details:

    Place of Origin: CHINA
    Brand Name: Mingrui
    Certification: SGS TUV ROHS
    Model Number: 0001

    Payment & Shipping Terms:

    Minimum Order Quantity: 2pcs
    Price: USD0.5-20/PCS
    Packaging Details: Normal box
    Delivery Time: 20-30 days
    Payment Terms: T/T, Western Union
    Supply Ability: 10PCS/Month
    Contact Now
    Detailed Product Description
    Material: Alumina Color: Ivory
    Name: Alumina Ceramic Parts

    95% high purity high temperature threaded alumina/zirconia ceramic rods

    1) A variety of specifications available.
    2) Satisfy various technical request
    3) High quality be sure
    4) Good insulation performance and high temperature resistance
    5) Bending strength and compressive strength resistance
    6) Used in all electric products and electric heating products
    7) OEM, ODM and OBM are welcomed

    We can offer the products base on customer's drawing, sample and other reference parameter

    ceramic sleeve bushing for machinery, precision 99.5% alumina ceramic sleeve and bushing, industrial ceramic sleeve and bushing, 99.5% alumina ceramic shaft piston rod for machinery, industrial ceramic shaft piston rod, ceramic

    Alumina ceramic is kind of structural ceramics, with insulation resistance, voltage resistance, high strength, good thermal conductivity, dielectric loss, stable electrical performance characteristics. Used in electronic ceramic substrates, ceramic electrical insulation, vacuum devices, devices porcelain, spark plugs and other products. We can make the part by hot injection pressing, dry pressing, 200T isostatic pressing and extrusion productive technology etc.
    MaterialUnitSteatite ceramics95% alumina ceramics99.5% alumina ceramics
    DensityG/cm32.73.73.9
    Highest application temperature°C110015001750
    Bending strengthMpa150300340
    Compressive strengthMpa90034003600
    HardnessHV0.580018002000
    Insulation breakdown strengthKV/mm101518
    Processing technology
    Process range (mm)
    Outside Diameter1---300
    Inside Diameter0.5---300
    Length0.5---1200
    Accuracy of working (mm)
    Perpendicularity0.01
    Concentricity0.01
    Roundness0.005
    Straightness 0.005
    Parallelism0.01
    Planeness0.005
    Roughness 0.05
    Fit clearance

    0.005


    Product show

    95% high purity high temperature threaded alumina/zirconia ceramic rods

    95% high purity high temperature threaded alumina/zirconia ceramic rods

    95% high purity high temperature threaded alumina/zirconia ceramic rods

    95% high purity high temperature threaded alumina/zirconia ceramic rods

    95% high purity high temperature threaded alumina/zirconia ceramic rods

    95% high purity high temperature threaded alumina/zirconia ceramic rods

    95% high purity high temperature threaded alumina/zirconia ceramic rods

    95% high purity high temperature threaded alumina/zirconia ceramic rods

    95% high purity high temperature threaded alumina/zirconia ceramic rods

    The other related products

    Ceramic parts

    95% high purity high temperature threaded alumina/zirconia ceramic rods

    95% high purity high temperature threaded alumina/zirconia ceramic rods

    95% high purity high temperature threaded alumina/zirconia ceramic rods

    Industrial Ceramic Application 95% Alumina Ceramic Parts Threaded Rod Screw Bolt

    95% high purity high temperature threaded alumina/zirconia ceramic rods


    95% high purity high temperature threaded alumina/zirconia ceramic rods

    95% high purity high temperature threaded alumina/zirconia ceramic rods

    Package and shipping

    High al2o3 tube insulators will be packed in a bubble bag individually, then separated by a foam, finally put in standard export carton packing, or OEM packing.
    Shipped by Express ( DHL, TNT, UPS, Fedex, EMS ), Air, or Sea transportation.

    95% high purity high temperature threaded alumina/zirconia ceramic rods

    95% high purity high temperature threaded alumina/zirconia ceramic rods

    Company information

    Who Are We?
    Mingrui has professional OEM experience in manufacturing industrial ceramic parts for so many
    years. We can make the products according to your drawings, custom the size, thickness and other parameters.
    What Do We Do?
    We have very advanced technologies in the production of zirconia and alumina ceramic nozzle, rod, ring, tube, shaft, plate, sleeve, valve, plunger, bearing, and semiconductive ceramics etc.. They are applicable to Electrical, Appliance, Mining, Oil & Gas, Energy & Power, Food & Medical, Agriculture, Aerospace,
    even other High-end fields.

    Our products with some certificates, such as , CE, TUV, etc..

    Factory information

    95% high purity high temperature threaded alumina/zirconia ceramic rods
    Production process show

    One-stop production, from the raw material ( powder ) to final products, control the quality strickly of every production link.

    95% high purity high temperature threaded alumina/zirconia ceramic rods

    Welcome to contact for the quotation, 2D/3D drawing will be perfect !
