95%-99.99% Alumina 95% Zirconia Ceramic Thermal Rods Piston Pump/ Plunger Shaft

95%-99.99% Alumina 95% Zirconia Ceramic Thermal Rods Piston Pump/ Plunger Shaft

    • 95%-99.99% Alumina 95% Zirconia Ceramic Thermal Rods Piston Pump/ Plunger Shaft
    • 95%-99.99% Alumina 95% Zirconia Ceramic Thermal Rods Piston Pump/ Plunger Shaft
    • 95%-99.99% Alumina 95% Zirconia Ceramic Thermal Rods Piston Pump/ Plunger Shaft
  • 95%-99.99% Alumina 95% Zirconia Ceramic Thermal Rods Piston Pump/ Plunger Shaft

    Product Details:

    Place of Origin: CHINA
    Brand Name: OEM
    Certification: TUV ROHS SGS
    Model Number: 0002

    Payment & Shipping Terms:

    Minimum Order Quantity: 2pcs
    Price: USD0.5-20/PCS
    Packaging Details: Normal box
    Delivery Time: 20-30 days
    Payment Terms: T/T, Western Union
    Supply Ability: 10PCS/Month
    Contact Now
    Detailed Product Description
    Color: Ivory Name: Alumina Ceramic Parts
    Material: Alumina Certification: SGS ROHS TUV
    MOQ: 1-2pcs

    95%-99.99% Alumina 95% Zirconia Ceramic Thermal Rods Piston Pump/ Plunger Shaft

    We can offer the products base on customer's drawing, sample and other reference parameter

    ceramic sleeve bushing for machinery, precision 99.5% alumina ceramic sleeve and bushing, industrial ceramic sleeve and bushing, 99.5% alumina ceramic shaft piston rod for machinery, industrial ceramic shaft piston rod, ceramic

    Alumina ceramic is kind of structural ceramics, with insulation resistance, voltage resistance, high strength, good thermal conductivity, dielectric loss, stable electrical performance characteristics. Used in electronic ceramic substrates, ceramic electrical insulation, vacuum devices, devices porcelain, spark plugs and other products. We can make the part by hot injection pressing, dry pressing, 200T isostatic pressing and extrusion productive technology etc.
    Material Unit Steatite ceramics 95% alumina ceramics 99.5% alumina ceramics
    Density G/cm3 2.7 3.7 3.9
    Highest application temperature °C 1100 1500 1750
    Bending strength Mpa 150 300 340
    Compressive strength Mpa 900 3400 3600
    Hardness HV0.5 800 1800 2000
    Insulation breakdown strength KV/mm 10 15 18
    Processing technology
    Process range (mm)
    Outside Diameter 1---300
    Inside Diameter 0.5---300
    Length 0.5---1200
    Accuracy of working (mm)
    Perpendicularity 0.01
    Concentricity 0.01
    Roundness 0.005
    Straightness 0.005
    Parallelism 0.01
    Planeness 0.005
    Roughness 0.05
    Fit clearance

    0.005


    1) A variety of specifications available.
    2) Satisfy various technical request
    3) High quality be sure
    4) Good insulation performance and high temperature resistance
    5) Bending strength and compressive strength resistance
    6) Used in all electric products and electric heating products
    7) OEM, ODM and OBM are welcomed

    95%-99.99% Alumina 95% Zirconia Ceramic Thermal Rods Piston Pump/ Plunger Shaft
    Company information
    Who Are We?
    Mingrui has professional OEM experience in manufacturing industrial ceramic parts for so many
    years. We can make the products according to your drawings, custom the size, thickness and other parameters.
    What Do We Do?
    We have very advanced technologies in the production of zirconia and alumina ceramic nozzle, rod, ring, tube, shaft, plate, sleeve, valve, plunger, bearing, and semiconductive ceramics etc.. They are applicable to Electrical, Appliance, Mining, Oil & Gas, Energy & Power, Food & Medical, Agriculture, Aerospace,
    even other High-end fields.
    Our products with some certificates, such as , CE, TUV, etc..

    Product show

    95%-99.99% Alumina 95% Zirconia Ceramic Thermal Rods Piston Pump/ Plunger Shaft

    95%-99.99% Alumina 95% Zirconia Ceramic Thermal Rods Piston Pump/ Plunger Shaft

    95%-99.99% Alumina 95% Zirconia Ceramic Thermal Rods Piston Pump/ Plunger Shaft

    95%-99.99% Alumina 95% Zirconia Ceramic Thermal Rods Piston Pump/ Plunger Shaft

    The other related products

    Ceramic parts

    95%-99.99% Alumina 95% Zirconia Ceramic Thermal Rods Piston Pump/ Plunger Shaft

    95%-99.99% Alumina 95% Zirconia Ceramic Thermal Rods Piston Pump/ Plunger Shaft

    95%-99.99% Alumina 95% Zirconia Ceramic Thermal Rods Piston Pump/ Plunger Shaft

    Industrial Ceramic Application 95% Alumina Ceramic Parts Threaded Rod Screw Bolt

    95%-99.99% Alumina 95% Zirconia Ceramic Thermal Rods Piston Pump/ Plunger Shaft


    95%-99.99% Alumina 95% Zirconia Ceramic Thermal Rods Piston Pump/ Plunger Shaft

    95%-99.99% Alumina 95% Zirconia Ceramic Thermal Rods Piston Pump/ Plunger Shaft

    Package and shipping

    High al2o3 tube insulators will be packed in a bubble bag individually, then separated by a foam, finally put in standard export carton packing, or OEM packing.
    Shipped by Express ( DHL, TNT, UPS, Fedex, EMS ), Air, or Sea transportation.

    95%-99.99% Alumina 95% Zirconia Ceramic Thermal Rods Piston Pump/ Plunger Shaft

    95%-99.99% Alumina 95% Zirconia Ceramic Thermal Rods Piston Pump/ Plunger Shaft

    Production process show

    One-stop production, from the raw material ( powder ) to final products, control the quality strickly of every production link.

    95%-99.99% Alumina 95% Zirconia Ceramic Thermal Rods Piston Pump/ Plunger Shaft

    Welcome to contact for the quotation, 2D/3D drawing will be perfect !
