Product Details
Place of Origin: CHINA
Brand Name: MH
Certification: ISO9001 RoHS
Model Number: MH-81521
Payment & Shipping Terms
Minimum Order Quantity: 1000 pcs
Price: USD 0.1-0.3 PCS
Packaging Details: Export carton
Delivery Time: 10-15 DAYS
Payment Terms: L/C, T/T, Western Union
Supply Ability: 8000 PCS WEEK
Material: |
95%Alumina Ceramic |
Color: |
White |
Temperature Resistance: |
1400°C |
Density: |
3.6 G/cm³ |
Hardness: |
10.7 Gpa |
Thermal Conductivity: |
20 W/(m.k) |
OEM,ODM: |
Acceptable |
Origin: |
China |
Material: |
95%Alumina Ceramic |
Color: |
White |
Temperature Resistance: |
1400°C |
Density: |
3.6 G/cm³ |
Hardness: |
10.7 Gpa |
Thermal Conductivity: |
20 W/(m.k) |
OEM,ODM: |
Acceptable |
Origin: |
China |
Features & Advantages
1. High hardness.
2. High heat resistance: alumina ceramic has excellentthermal stability,which means that it is widely used in areas where resistance to high temperatures is essential.
3. Good wear resistance: alumina ceramic is the material of choice for alumina wear parts.
4. High electrical resistivity: alumina is an electrically insulating material.
5. High corrosion resistance: it is insoluble in water and only slightly soluble in strong acid and alkaline solutions. Good chemical stability of alumina leads to high corrosion resistance.
Alumina ceramic is a kind of material based on alumina (Al2O3), which is used in thick film integrated circuit. Alumina ceramics have good conductivity, mechanical strength and high temperature resistance. It needs to be noted that ultrasonic cleaning is needed. Alumina ceramic is a kind of widely used ceramic. Because of its superior performance, it has been widely used in modern society, meeting the needs of daily use and special performance.
| Properties | Unit | Steatite ceramic | 95% Al2O3 | 99% Al2O3 | Zirconia Ceramic |
| Density | g/cm³ | 2.8 | 3.6 | 3.8 | 5.6 |
| Flexural strength | Mpa | 145 | 300 | 300 | 354 |
| Max Working Temperature | ℃ | 1100 | 1400 | 1600 | 1400 |
| Sintering temperature | ℃ | 1350 | 1700 | 1750 | 1550 |
| Heat resistance | T(℃) | 200 | 220 | 200 | 350 |
| Hardness | Gpa | 5.7 | 7 | 10.7 | 12.3 |
| Elastic modulus | Gpa | 120 | 275 | 320 | 205 |
| Poissons ratio | - | 0.21 | 0.22 | 0.22 | 0.30 |
| Linear expansion coefficient | x 10-6/℃ | 7.9 | 7.1 | 7.8 | 9 |
| Insulation breakdown Intensity | KT/mm | 10 | 16 | 18 | 15 |
| Thermal conductivity | w/(m.k) | 2.5 | 20 | 25 | 2.5 |
| Specific Heat | *10-3J/(kg*K) | 0.75 | 0.78 | 0.78 | 0.4 |
