High Temperature Industrial Ceramic Steatite 2.8g/Cm3 Ceramic Heating Element

Product Details

Place of Origin: China

Brand Name: MH

Certification: RoHS ISO9001

Model Number: MH-65819

Payment & Shipping Terms

Minimum Order Quantity: 1000

Price: 0.5-1usd /pcs

Packaging Details: export carton

Delivery Time: 8-10

Payment Terms: D/A, D/P, T/T, D/A

Supply Ability: 3000 pcs /day

Get Best Price
High Light:

high temperature industrial ceramic

,

industrial ceramic ISO9001

,

2.8g/cm3 ceramic heating element

Material:
Steatite Ceramic
Color:
White Yellow
Size:
Size Customized
Usage:
Industrial Ceramic
Working Temperature:
1300 ℃
Sample:
Free Sample
MOQ:
1000
Density:
2.8 G/cm3
Origin:
China
OEM,ODM:
Accept
Material:
Steatite Ceramic
Color:
White Yellow
Size:
Size Customized
Usage:
Industrial Ceramic
Working Temperature:
1300 ℃
Sample:
Free Sample
MOQ:
1000
Density:
2.8 G/cm3
Origin:
China
OEM,ODM:
Accept
High Temperature Industrial Ceramic Steatite 2.8g/Cm3 Ceramic Heating Element

high temperature insulator steatite ceramic heating element



Steatite Ceramic



Steatite is an inorganic material based on natural raw materials consisting predominantly of magnesium silicate. It is marked by a high heat resistance, resistance to leakage current and dielectric strength. It is recommended as an insulation material in electrical engineering.

Main Applications:
1). Shaft, Plunger
2). High-pressure cleaning machines
3). Sealing structure
4). Auto mobile industry
5). Oil drilling equipment
6). Insulation parts in electrical equipment
7). Ceramic knife
8). Ceramic hair clipper spare parts



Properties Unit Steatite ceramic 95% Al2O3 99% Al2O3 Zirconia Ceramic
Density g/cm³ 2.8 3.6 3.8 5.6
Flexural strength Mpa 145 300 300 354
Max Working Temperature 1100 1400 1600 1400
Sintering temperature 1350 1700 1750 1550
Heat resistance T(℃) 200 220 200 350
Hardness Gpa 5.7 7 10.7 12.3
Elastic modulus Gpa 120 275 320 205
Poissons ratio - 0.21 0.22 0.22 0.30
Linear expansion coefficient x 10-6/℃ 7.9 7.1 7.8 9
Insulation breakdown Intensity KT/mm 10 16 18 15
Thermal conductivity w/(m.k) 2.5 20 25 2.5
Specific Heat *10-3J/(kg*K) 0.75 0.78 0.78 0.4
